In the world of self-service touch screen Kiosks, the touchscreen is more than just a display; it is the primary gateway for human-machine interaction. From automated retail to smart healthcare, the choice of touch technology determines the user experience (UX), the durability of the hardware, and the Total Cost of Ownership (TCO) for operators.
PCAP is the current gold standard for high-end kiosks, such as the Film Application and Case Printing series.
How it Works: It utilizes a conductive grid (usually ITO) layered behind a protective glass cover. When a finger approaches the surface, it creates a change in capacitance, which the controller triangulates into precise coordinates.
Multi-touch Capability: Supports 10+ touch points, enabling gestures like pinching and zooming.
Industrial Durability: Since the sensors are protected by tempered glass, the touch function remains unaffected by surface scratches or heavy wear.
Sleek Aesthetics: Allows for "True Flat" edge-to-edge glass designs with no raised bezels, making it easy to clean and modern in appearance.
Optical Clarity: High light transmission ensures that 4K/UHD content remains vibrant.
IR technology is the preferred choice for large-format displays and extreme environments.
How it Works: An array of IR LEDs and photodetectors are embedded in the frame of the kiosk, creating a dense "grid" of light beams across the surface.
Input Versatility: Responds to any object (fingers, gloved hands, or styluses), which is critical for outdoor kiosks in cold climates or industrial workshops.
Scalability: Highly cost-effective for large screens (55" to 98").
Zero Pressure Required: Offers a very light touch sensation, reducing physical strain on the screen over time.
|
|
In public environments, standard glass is insufficient. High-performance kiosks utilize specific coatings to maintain legibility and hygiene:
Treatment | Full Name | Functional Role |
AG Coating | Anti-Glare | Diffuses reflections from overhead lights or sun, ensuring content is visible in bright malls. |
AR Coating | Anti-Reflection | Increases light transmission and reduces "mirroring" effects on the glass. |
AF Coating | Anti-Fingerprint | An oleophobic layer that resists oil and smudges, keeping the screen clean during high-traffic use. |
For a B2B buyer, matching the technology to the application is vital for ROI.
Application | Recommended Tech | Rationale |
Food/Retail (21.5"-32") | PCAP | High sensitivity, easy to wipe clean, supports modern UI gestures. |
Outdoor Wayfinding | IR + High Brightness | Works with gloves, handles extreme temperature fluctuations better. |
Hospital/Medical | PCAP + Antimicrobial | Flat surface allows for medical-grade disinfection; supports antimicrobial coatings. |
Large Info Totems (55"+) | IR | Cost-efficient for large surfaces; highly reliable for simple navigation. |
 |
At KosinTec, we integrate touch technology with industrial-grade controllers (such as EETI or ILITEK) to solve common field issues:
Palm Rejection: Prevents accidental triggers when a user leans on the screen.
Water-Drop Rejection: Advanced firmware ensures the screen remains functional even if splashes or rain droplets are on the surface.
Fast Response Time: We guarantee a latency of ≤ 6 ms, preventing user frustration during rapid typing or navigation.
Haptic Feedback: Integrating micro-vibrations to simulate the feeling of physical buttons, providing tactile confirmation for payments.
Antimicrobial Glass: Silver-ion integrated glass that continuously kills 99.9% of bacteria, essential for post-pandemic public health.
Touchless Interaction: Using IR sensors or computer vision to detect "hover" gestures, allowing users to interact without physically touching the surface.
The touchscreen is not just a component; it is the soul of the kiosk. A failure in touch responsiveness is a failure in customer service. By choosing KosinTec, you are opting for a system where touch accuracy, surface durability, and industrial stability are engineered into a single, cohesive unit.
